SPINE | PESO TUBO GPI | Ø EXTERIOR | LONGITUD | 100-120 GRN | 90-110 GRN | 70-90 GRN | 60-80 GRN | PIN 4MM | COLLAR 4MM | |
340 | 8.8 | .240" | 33.25" | #4 | #4 | #7 | ||||
400 | 7.9 | .234" | 33.00" | #4 | #4 | #5 | ||||
450 | 7.4 | .230" | 32.75" | #4 | #4 | #4 | ||||
500 | 6.9 | .227" | 32.50" | #4 | #4 | #4 | ||||
550 | 6.5 | .224" | 32.25"" | #3 | #3 | #4 | ||||
600 | 6.5 | .224" | 32.00" | #3 | #3 | #4 | ||||
660 | 6.2 | .220" | 31.75" | #3 | #3 | #3 | ||||
730 | 5.7 | .217" | 31.25" | #3 | #2 | #3 | ||||
810 | 5.5 | .215" | 31.00" | #2 | #2 | #2 | ||||
900 | 5.2 | .211" | 30.25" | #2 | #2 | #2 | ||||
1000 | 4.9 | .209" | 30.00" | #2 | #2 | #2 | ||||
1150 | 4.9 | .208" | 29.25" | #2 | #2 | #2 | ||||
1400 | 4.2 | .205" | 29.00" | #1 | #1 | #1 | ||||
1600 | 3.8 | .202" | 28.75" | #1 | #1 | #1 | ||||
1800 | 3.6 | .200" | 28.50" | #1 | #1 | #1 | ||||
2000 | 3.4 | .198" | 28.25" | #1 | #1 | #1 |
